Industrial Gas Burner BNG15

Question 1-Product Description

SHORT DESCRIPTION

♦ Gas burner.

♦ Single-stage operation.

♦ Air-gas mixing at the air duct.

♦ By adjusting the combustion air and the air duct, it is possible to obtain the best combustion values.

♦ The atomizing device can be removed without removing the burner from the boiler, which facilitates maintenance.

♦ Manual air flow regulation.

♦ One flange and one insulating seal for boiler fixing.

♦ Combustion air inlet with air flow regulation.

♦ Sliding boiler coupling flange to adapt to the head protrusion of various types of boilers.

♦ Single-phase electric motor runs the fan.

♦ Flame presence check by ionization electrode.

♦ Electrical equipment protection level IP40.

PRODUCT VIDEO

VIDEO LIST:

1.How to control the fire

2.Test of BNG15/Oman customers/Ignition test

Question 2-Product Parameter

BNG15 PARAMETERS

Model	BNG15
Fuel	Natural Gas (NG)| Propane (LP)|Propane Air Mix (LA)|Town Gas (TG) Digester Gas (DG)
Power(kw)	50-150
Gas Flow(m3/h)	5-16
Power Supply	1N AC 50HZ 220V
Moter Power(kw)	0.18
Combustion Chamber Pressure(mbar)	3
Control	One stage
Packing Size(mm)	580*465*350
Weight(kg)	16

SMALLER POWER MODEL PARAMETERS

Model	BNG6	BNG10
Power(kw)	30-58	50-100
Gas Flow(m3/h)	3-5.8	5-10
Power Supply	1N AC 50HZ 220V	1N AC 50HZ 220V
Combustion Chamber Pressure(mbar)	2.5	2.8
Control	One stage	One stage

*For more parameters, please contact: info@bntet.com

Question 3-Product Display

Question 4-Application

Our experience in nearly all types of industrial burner applications ensures you of quality products that meet the rigorous demands of your operation.

Question 5-FAQ

Q:How do I get the product catalogue?

A:Please contact with us by email or whatsapp,we will send your the catalogue asap.

Question 6-Our service

PACKAGING

CASE

Oman customer’s gas burner order completed→
